WPLRC Schema

Preamble

WPLRC is the intermediate lyric format used by WpfMusicPlayer. It is a UTF-8 encoded JSON format designed to preserve the semantic order of lyric text, translations, romanization lines, and optional word-level timing controller nodes after traditional LRC input has been normalized.

It is designed to be a successor format of traditional LRC, which has no clear schemes, no standards, and cannot preserve the semantic information between lyric nodes.

The current format version is 2.

Status

This document describes WPLRC format version 2 as produced by LrcFileControllerNative::to_intermediate_json and consumed by the managed lyric pipeline in WpfMusicPlayer.

Version 2 moves romanization schema information to the document root. Legacy version 1 documents may contain per-line schema or scheme properties; WpfMusicPlayer upgrades those documents to version 2 by inferring the dominant root-level romanization_schema and removing the per-line schema fields.

File Format

A WPLRC file:

MUST be valid standard JSON. JSON comments are not allowed.
SHOULD be encoded as UTF-8. WpfMusicPlayer exports UTF-8 without BOM.
SHOULD use the .wplrc file extension.
MUST contain a top-level JSON object.

All time values are integers measured in milliseconds.

Top-Level Object

Property	Type	Required for v2 producers	Description
`format_version`	integer	Yes	Format version. Current value is `2`.
`romanization_schema`	string	No	Global romanization notation schema. Valid values are `romaji` and `jyutping`. Omit when no romanization schema is active.
`offset`	integer	Yes	Global lyric offset in milliseconds. Positive values delay lyrics; negative values advance lyrics. Consumers SHOULD default missing offsets to `0` for compatibility.
`metadata`	object	Yes	Metadata converted from LRC tags. May be an empty object.
`lyric_lines`	array	Yes	Ordered array of lyric line nodes.

Consumers SHOULD reject documents whose format_version is unsupported. WpfMusicPlayer currently accepts version 1 for upgrade and version 2 as the current format.

Metadata Object

The metadata object contains optional string fields. Producers SHOULD omit empty metadata fields.

Property	Source LRC tags	Description
`artist`	`ar`, `artist`	Artist name.
`album`	`al`, `album`	Album name.
`author`	`au`, `author`	Lyric author.
`by`	`by`	LRC file creator/uploader field.
`title`	`ti`, `title`	Song title.

The LRC [offset:...] tag is represented by the top-level offset property, not inside metadata.

Lyric Line Object

Each item in lyric_lines represents one timed lyric group.

Property	Type	Required	Description
`time_start_ms`	integer	Yes	Start time of this lyric group.
`time_end_ms`	integer	Yes	End time of this lyric group.
`lines`	array	Yes	Semantic line nodes that belong to this timed group.

lyric_lines SHOULD be sorted by ascending time_start_ms. A producer SHOULD ensure time_end_ms > time_start_ms; and if a consumer is procedding with a node with time_start_ms > time_end_ms, it SHOULD fail immediately. If an LRC line has no explicit end time, WpfMusicPlayer derives it from the next line start time, from word-level controller timing, from song duration when available, or from a minimal non-zero fallback duration.

Line Node Object

Each item in a lyric line’s lines array represents one semantic text line.

Property	Type	Required	Description
`role`	string	Yes	Semantic role. Valid values are `lyric`, `translation`, `romanization`, and `ignored`.
`language`	string	Recommended	Detected language classifier output. See valid values below.
`text`	string	Required when `sync` is absent; when `sync` is present, it will be discarded into silence.	Plain text for this semantic line.
`sync`	string	No	Synchronization type. Use `controller_nodes` for word-level timing.
`controller_nodes`	array	Required when `sync` is `controller_nodes`	Word-level or segment-level timing controller nodes.

Valid language values currently produced by WpfMusicPlayer are:

zh — Simplified Chinese / Traditional Chinese
latin — English / France / Italian / Spanish, and / or other latin-based languages
jp — Japanese, with Hiragana, Katakana, and Kanji
kr — Korean, with Hangul letters and Hanja
ru — Russian / Mongolia , and / or other cyrillic alphabet-based languages
jyut — Cantonese Jyutping and Hanyu Pinyin
roma — Romanization of Japanese and Korean
onomatopoeia — Onomatopoeia with no actual meaning, or other unrecogized languages

Consumers SHOULD treat unknown role, language, or sync values conservatively. WpfMusicPlayer reads roles case-insensitively and uses the first lyric role as the primary display line. If no lyric role exists, it falls back to the first line node in the group.

Controller Nodes

When a line node has "sync": "controller_nodes", the line uses timed controller nodes instead of plain text timing.

Property	Type	Required	Description
`time_start_ms`	integer	Yes	Start time of this controller segment.
`time_end_ms`	integer	Yes	End time of this controller segment.
`text`	string	Yes	Text displayed during this controller segment.

Controller node times are absolute document times in milliseconds, not offsets relative to their parent line.

A controller-synchronized line SHOULD omit text; consumers can reconstruct the display text by concatenating controller_nodes[*].text in order, discarding the text property into silence. WpfMusicPlayer does this reconstruction when text is absent.

For highlight progress, WpfMusicPlayer interpolates linearly inside each controller node and maps the active node index plus local progress to the whole line’s progress. Empty controller node text is ignored by the managed display pipeline.

For legacy compatibility, WpfMusicPlayer also recognizes sync: "controller_node" as equivalent to sync: "controller_nodes", but version 2 producers SHOULD write only controller_nodes.

Romanization Schema

romanization_schema is a document-level property in version 2. It describes the notation system used by lines whose role is romanization.

Valid values:

romaji: romanized Japanese or Korean-style romanization as classified by the WpfMusicPlayer lyric engine.
jyutping: Cantonese Jyutping and / or Hanyu Pinyin.

If romanization_schema is missing or unknown, consumers SHOULD treat romanization as present only when romanization role lines exist, but SHOULD NOT assume a specific notation system.

Version 2 line nodes MUST NOT use schema or scheme. Consumers MAY remove those fields during normalization.

Example

This is a complete WPLRC version 2 document. The example is valid JSON and contains no comments.

{
  "format_version": 2,
  "romanization_schema": "romaji",
  "offset": 0,
  "metadata": {
    "artist": "sample",
    "album": "sample",
    "author": "sample",
    "by": "sample",
    "title": "sample"
  },
  "lyric_lines": [
    {
      "time_start_ms": 12060,
      "time_end_ms": 13843,
      "lines": [
        {
          "role": "romanization",
          "sync": "controller_nodes",
          "language": "roma",
          "controller_nodes": [
            {
              "time_start_ms": 12060,
              "time_end_ms": 12215,
              "text": "ba "
            },
            {
              "time_start_ms": 12216,
              "time_end_ms": 12371,
              "text": "'d "
            },
            {
              "time_start_ms": 12371,
              "time_end_ms": 12507,
              "text": "do "
            },
            {
              "time_start_ms": 12508,
              "time_end_ms": 12655,
              "text": "ra "
            },
            {
              "time_start_ms": 12656,
              "time_end_ms": 12803,
              "text": "n "
            },
            {
              "time_start_ms": 12803,
              "time_end_ms": 12955,
              "text": "do "
            },
            {
              "time_start_ms": 12956,
              "time_end_ms": 13123,
              "text": "ni "
            },
            {
              "time_start_ms": 13123,
              "time_end_ms": 13275,
              "text": "u "
            },
            {
              "time_start_ms": 13276,
              "time_end_ms": 13428,
              "text": "ma "
            },
            {
              "time_start_ms": 13428,
              "time_end_ms": 13556,
              "text": "re "
            },
            {
              "time_start_ms": 13557,
              "time_end_ms": 13843,
              "text": "ta "
            }
          ]
        },
        {
          "role": "lyric",
          "language": "jp",
          "text": "バッドランドに生まれた"
        },
        {
          "role": "translation",
          "language": "zh",
          "text": "只因诞生于劣地"
        }
      ]
    },
    {
      "time_start_ms": 13843,
      "time_end_ms": 16267,
      "lines": [
        {
          "role": "romanization",
          "sync": "controller_nodes",
          "language": "roma",
          "controller_nodes": [
            {
              "time_start_ms": 13843,
              "time_end_ms": 13987,
              "text": "da "
            },
            {
              "time_start_ms": 13987,
              "time_end_ms": 14154,
              "text": "ke "
            },
            {
              "time_start_ms": 14154,
              "time_end_ms": 14313,
              "text": "de "
            },
            {
              "time_start_ms": 14314,
              "time_end_ms": 14474,
              "text": "ba "
            },
            {
              "time_start_ms": 14474,
              "time_end_ms": 14634,
              "text": "'d "
            },
            {
              "time_start_ms": 14635,
              "time_end_ms": 14786,
              "text": "do "
            },
            {
              "time_start_ms": 14786,
              "time_end_ms": 14938,
              "text": "ra "
            },
            {
              "time_start_ms": 14939,
              "time_end_ms": 15116,
              "text": "i "
            },
            {
              "time_start_ms": 15116,
              "time_end_ms": 15258,
              "text": "fu "
            },
            {
              "time_start_ms": 15258,
              "time_end_ms": 15417,
              "text": "ga "
            },
            {
              "time_start_ms": 15418,
              "time_end_ms": 15554,
              "text": "de "
            },
            {
              "time_start_ms": 15555,
              "time_end_ms": 15630,
              "text": "fo "
            },
            {
              "time_start_ms": 15706,
              "time_end_ms": 15842,
              "text": "to "
            },
            {
              "time_start_ms": 15843,
              "time_end_ms": 16266,
              "text": "ka "
            }
          ]
        },
        {
          "role": "lyric",
          "language": "jp",
          "text": "だけでバッドライフがデフォとか"
        },
        {
          "role": "translation",
          "language": "zh",
          "text": "就默认会拥有糟糕的人生吗"
        }
      ]
    }
  ]
}

Minimal Example

{
  "format_version": 2,
  "offset": 0,
  "metadata": {},
  "lyric_lines": [
    {
      "time_start_ms": 1000,
      "time_end_ms": 5500,
      "lines": [
        {
          "role": "lyric",
          "language": "latin",
          "text": "First line"
        }
      ]
    }
  ]
}

Version Compatibility

WPLRC version 1 is a legacy intermediate format. Its known difference is that romanization schema may appear on individual line nodes as schema or scheme.

When upgrading version 1 to version 2, and current WPLRC version 1 has romanization line nodes, WpfMusicPlayer:

Counts recognized per-line schema values.
Chooses jyutping if it appears more often than romaji; otherwise chooses romaji when any recognized romanization schema exists.
Writes the chosen value to root-level romanization_schema.
Sets format_version to 2.
Removes all per-line scheme(and schemea, if contains) properties.

Otherwise, it does not produce romanization_schema root property.

Version 2 producers SHOULD NOT emit version 1 fields.

Producer Notes

The WpfMusicPlayer LRC converter currently normalizes several LRC patterns into WPLRC:

Plain line-timed LRC.
Multiple time tags on one LRC line.
Out-of-order LRC timestamps, sorted stably by time.
Interleaved or synchronized translation lines.
Inline translations in supported patterns.
Extended LRC or word-level timing nodes using <mm:ss.xxx> or [mm:ss.xxx] style controller markers.

Those source-LRC heuristics are producer behavior, not additional WPLRC syntax. A WPLRC reader only needs to implement the JSON format described above.
